MODEL UNIT	300	400	500	600	700
Work table mm	600x300	650x350	800x400	950x500	1000x600
Work tank (X x Z x Y) mm	770x500x350	940x580x400	1140x630x450	1470x920x600	1500x1020x650
Maximum oil depth (From worktable) mm	240	280	320	470	540
Table longitudinal travels (X) mm	300	400	500	600	700
Table transversal travels (Y) mm	250	300	400	500	500
Z AXIS TRAVEL-Quill travel mm	150	180	180	250	400/600
Z AXIS TRAVEL-Backslide travel mm	230	300	400	400	-
Worktable “T” slot (# x P) mm	3x100	4x70	4x85	5x85	4x130
Max distance between the table surface and quill (Option) mm	420	450	550	760(960)	750(900/1150)
Maximum electrode weight mm	50	150	200	250	300
Maximum workpiece weight KGS	700	1000	1500	4000	4000
Machine weight KGS	1400	1800	2150	3500	5500
Max machining current power input (Standard) AMP	75	75	75	100	100

MODEL UNIT	1000	1300	2000	2100	2500
Work table mm	1200x800	1400x900	2000x1000	2000x1000	2500x1000
Work tank (X x Z x Y) mm	1845x1100x650	2080x1270x700	2900x1500x700	2900x1500x700	3400x1555x700
Maximum oil depth (From worktable) mm	540	540	450	450	640
Table longitudinal travels (X) mm	1000	1300	2000	2100	2500
Table transversal travels (Y) mm	600	700	1000	1000	1000
Z AXIS TRAVEL-Quill travel mm	400/600	450/600	600	600	600
Z AXIS TRAVEL-Backslide travel mm	-	-	-	-	-
Worktable “T” slot (# x P) mm	6x130	6x145	6x147	6x147	6x147
Max distance between the table surface and quill (Option) mm	730(980x1180)	910(1260)	950(1350)	950(1350)	950(1350)
Maximum electrode weight mm	300	500	500	500	500
Maximum workpiece weight KGS	5000	5000	7000	9000	10000
Machine weight KGS	7000	8400	12300	13500	18200
Max machining current power input (Standard) AMP	150	150	150	150	150
