Standard Accessories BT/CAT/DIN-40 Standard Spindle 8000rpm (Belt Driven) Electrical Cabinet with Heat Exchanger Spindle Coolant Nozzle System RS232 Interface Spindle Air Blast Fluorescent Work Light Lubrication System (proportional pressured) Alarm Lamp Auto Interrupt & Power Off System Tool Box & Tools Portable Hand Wheel Leveling Blocks & Bolts Operation Manual, Maintenance Manual Fully Enclosed Splash Guard CNC Manual Rigid Tapping Test Report In CD Format Optional Accessories Spindle Belt Drive (rpm) 10000, 12000 Spindle Direct Drive (rpm) 10000, 12000, 15000 Spindle Built-in 24000, 30000 Spindle Motor Upgrade Available Spindle Oil Coolant System Available 4th Axis (Rotary Table) Available 4th Axis Preparation Available Air Gun System Available ATC - Carousel Type BT/CAT/DIN-40/50 16 Tool ATC - Swing ARM Type BT/CAT/DIN-40/50 24 Tool Chip Conveyor System Belt Type / Scrapper Type Chip Conveyor System Internal Type Coolant Through Spindle (CTS) 15 - 20 bar Flushing System + Water Gun Available Linear Scale Heidenhain LS Oil Skimmer / Separator Available Tool Probe TS-27R , NC4 Transformer 35 KVA Workpiece Measurement Device MP12 , OMP40 60 Z/F Gear Box Available Technical Specifications Travel (mm)  X-axis 1400mm Y-axis 700mm Z-axis 650mm Spindle Nose To Work Table Surface  150 - 800mm Work Table Table size (L x W) 1500 * 600mm T-Slot 5 * 18 * 100mm Maximum Table Load 1000 kgs Maximum Traverse Speed  X-axis 24m/min Y-axis 24m/min Z-axis 24m/min Position Accuracy  X, Y & Z *+/-.005mm Repeatability Accuracy  X, Y & Z *+/-.002mm Guide Way (Roller Guide Way) X-axis 2 Roller Guide Way (SP) Y-axis 4 Roller Guide Way (SP) Z-axis 2 Roller Guide Way (SP) Lubricating System  Oil Cooled Lubricator 2 x Lubricator WAY LUBE 68 Spindle Spindle Taper  40/50 Spindle Motor  11 KW (standard) - 15 KW (optional) Other Air Supply Required  6Kg / square cm Power Supply Required  35 KVA Machine Weight 8000 kgs Machine Dimension For Shipping  390*232*256cm (40'HQ)
