Standard Accessories
BT/CAT/DIN-40 Standard Spindle 8000rpm (Belt Driven)
Electrical Cabinet with Heat Exchanger Spindle Coolant Nozzle System
RS232 Interface Spindle Air Blast
Fluorescent Work Light Lubrication System (proportional pressured)
Alarm Lamp Auto Interrupt & Power Off System
Tool Box & Tools Portable Hand Wheel
Leveling Blocks & Bolts Operation Manual, Maintenance Manual
Fully Enclosed Splash Guard CNC Manual
Rigid Tapping Test Report In CD Format
Optional Accessories
Spindle Belt Drive (rpm) 10000, 12000
Spindle Direct Drive (rpm) 10000, 12000, 15000
Spindle Built-in 24000, 30000
Spindle Oil Coolant System Available
4th Axis (Rotary Table) Available
4th Axis Preparation Available
Air Gun System Available
ATC - Carousel Type BT/CAT/DIN-40 16 Tool
ATC - Swing ARM Type BT/CAT/DIN-40 24 Tool
Chip Conveyor System Belt Type / Scrapper Type
Chip Conveyor System Internal Type
Coolant Through Spindle (CTS) 15 - 20 bar
Flushing System + Water Gun Available
Linear Scale Heidenhain LS
Oil Skimmer / Separator Available
Tool Probe TS-27R , NC4
Transformer 25KVA
Workpiece Measurement Device MP12 , OMP40 60
Z/F Gear Box Available
Technical Specifications
Travel (mm)
X-axis 850mm
Y-axis 500mm
Z-axis 550mm
Spindle Nose To Work Table Surface  150 - 700mm
Work Table
Table size (L x W) 1080 * 510mm
T-Slot 5 * 18 * 100mm
Maximum Table Load 700 kgs
Maximum Traverse Speed
X-axis 30/36m/min
Y-axis 30/36m/min
Z-axis 30/36m/min
Position Accuracy
X, Y & Z *+/-.005mm
Repeatability Accuracy
X, Y & Z *+/-.002mm
Guide Way (Roller Guide Way)
X-axis 2 Roller Guide Way (SP)
Y-axis 2 Roller Guide Way (SP)
Z-axis 2 Roller Guide Way (SP)
Lubricating System  Oil Cooled
Lubricator 2 x Lubricator WAY LUBE 68
Spindle
Spindle Taper  40
Spindle Motor  11 KW
Other
Air Supply Required  6Kg / square cm
Power Supply Required  25 KVA
Machine Weight 6000 kgs
Machine Dimension For Shipping  282*232*256cm (40'HQ)
